Converting Machines


TTM Tray Converters

TTM Tray Converter

This converter was specially developed to produce a tray with frames such as often used to hold and display produce (tomatoes, eggplant, etc.), dried seafood, and similar goods.

ABM Tray Converters

ABM Tray Converters

The ABM series creates corrugated four-walled open trays (corrugated box bases) that are ideal for gifts and other such uses.

TF Tray Converters

TF Tray Converters

The TF series creates corrugated box covers for corrugated trays used for gifts and other such purposes.

CFC-10T Little Former (tape)

CFC-10T Little Former (tape)

More compact than conventional models; can be installed in tighter locations.

CFC-12G Little Former (tape)

CFC-12G Little Former (tape)

The melt-adhesion process uses high-speed cylinders (highly cushioned), offering fast processing and very durable adhesion.

CFH-2400T horizontal converter (tape)

CFH-2400T horizontal converter (tape)

High processing capacity and easy size change. Fully automated system allows unmanned operation.

CFH-1800G horizontal converter (melt)

CFH-1800G horizontal converter (melt)

High processing capacity enables improved productivity. Easy to change sizes.

CFH-3600G ultra high-speed horizontal converter (melt)

CFH-3600G ultra high-speed horizontal converter (melt)

Mechanical drive enables ultra-fast operation. High processing capacity and easy size change.

RA-1000 high-speed blank-sheet converter

RA-1000 high-speed blank-sheet converter

The "RA-1000"is a new type of automatic A-type case converter that simultaneously adheres the blank sheet's joint flap and bottom flaps.

HCF semiautomatic converter (melt)

HCF semiautomatic converter (melt)

Since folding is carried out manually, the machine supports many different conversion methods.



Converting Machines: System Flowchart

Conversion systems can be assembled to support many different sheets and
adhesion methods.

Conversion Methods Tape Using Kraft tape, OPP tape, and gummed tape (water-adhered) packaging tapes.
Hot-melt We use hot-melt applicators (from Nordson and others) to execute sealing in accordance with the manufacturers specifications.
Hot-melt + Cold Glue
Hot-melt + Tape
Staples
Types Semiautomatic Folding is carried out manually. All of the above-listed conversion methods are supported.
Compact Capacity: 10-15 cases/minute
Standard conversion machine
Vertical Capacity: 10-20 cases/minute
Sheet is opened by suction pad. (Both little former model and large model.)
Horizontal Capacity: 20-60 cases/minute
Mechanical fingers open flaps while sheet is in transport.
Optional Device A sheet feeder can be attached as an option.
Operational Adjustment Fixed (No Adjustment) Dedicated system, for a specific product.
Since the system is dedicated to a single product type, no adjustment is required. Consequently, cost-performance is very favorable.
Adjustment by Handle Can be handle-adjusted to support various products. We offer the maximum adjustment range available for each setup.
Random Automatically handles multiple types of conversion.
Preset Adjustments The system adjusts automatically to preset values when the operator inputs a product name.
Specifications RENGO Standard Specifications Packaging is produced using our standard designated components.
Special Specifications Packaging is produced to meet the customer's requested specifications.
Accessories Bar-code readers, ink-jet printers, labelers, and various other mountable devices.
Special-purpose Machines Bliss-box converter We can implement various designs to meet specific product requirements.
Tray converter We can implement various designs to meet specific product requirements.
H-sealed case foamer We can implement various designs to meet specific product requirements.
One-touch case converter We can implement various designs to meet specific product requirements.
